| Image Name: | 4 S0 inputs with Ethernet, 1wire and RS485 |
| Created: | Friday 30 of January, 2009 [14:20:45 UTC] |
| Image size: | 640x640 |
| imagescale: | original size |
| Hits: | 42803 |
| Description: | Prototype of a DIN rail 4 S0-port to Ethernet interface. With PoE Support and 1wire host. Feature board plugged with 7LED/1switch and RS485-Bus interface/connectors. |
| Author: | tostmann |
