EUL1x EUL1X
This product is no longer manufactured and cannot be ordered. The page stays online as a reference for devices still in use; specifications, prices and external links date from the time it was sold and may be out of date.
This module glues an EnOcean TCM310 transceiver to USB 2.0. The freely programmable microcontroller allows any kind of USB device favours. This hardware is not
EUL - EnOcean USB light - TCM310
General
This module glues an EnOcean TCM310 transceiver to USB 2.0. The freely programmable microcontroller allows any kind of USB device favours. This hardware is not just a serial-USB-bridge as many other EnOcean-USB-devices.
Specs
- TCM310 connected to USART of:
- ATmega32u4 @ 8MHz
- USB A male connector
- Whip or SMA antenna
- green LED
- dfu-bootloader - allows flashing firmware by using USB
- optional: plastic case
Documents
Firmware
- USB2TCM.hex - This will allow native access to TCM310 providing an emulated serial port (CDC ACM) on host PC ** @Windows: use this LUFA_USB2TCM.inf - Other OS will have native drivers. ** sources
- How to flash this device: **locate the PROGRAM button at the back of the module **keep it pressed while plugging the module in **run:
dfu-programmer atmega32u4 erase dfu-programmer atmega32u4 flash USB2TCM.hex dfu-programmer atmega32u4 reset
**optionally you may run: make dfu
Price and availability
This module is no longer available
