EUL - EnOcean? USB light - TCM310

Prototype V1.0

General

End-Of-Life

This module glues an EnOcean? TCM310 transceiver to USB 2.0. The freely programmable microcontroller allows any kind of USB device favours. This hardware is not just a serial-USB-bridge as many other EnOcean-USB-devices?.

Have a look at this modules Image Gallery

Specs

  • TCM310 connected to USART of:
  • ATmega32u4 @ 8MHz
  • USB A male connector
  • Whip or SMA antenna
  • green LED
  • dfu-bootloader - allows flashing firmware by using USB
  • optional: 2x3pin 100mil ISP feature connector
  • optional: plastic case

Documents

Firmware

  • USB2TCM.hex - This will allow native access to TCM310 providing an emulated serial port (CDC ACM) on host PC
  • How to flash this device:
    • locate the PROGRAM button at the back of the module
    • keep it pressed while plugging the module in
    • run:
dfu-programmer atmega32u4 erase
dfu-programmer atmega32u4 flash USB2TCM.hex
dfu-programmer atmega32u4 reset

    • optionally you may run: make dfu

Price and availability

This module is no longer available in our shop

Created by: tostmann last modification: Friday 05 of September, 2014 [11:48:27 UTC] by tostmann
