CC1101 with USB & Network - CUN

This module has retired - see CUNO for next generation!

General

CUN is a CC110x ISM transceiver with USB and Ethernet interface, MicroSD slot and additional memories.

Have a look at this modules Image Gallery ...

Specs

• AT90USB1287 processor 8MHz @ 3.3V
• CC1101 - ISM transceiver tuned for 868MHz
• RP-SMA edge-pinheader
• ENC28J60 Ethernet
• ext. 2MB data flash
• ext. 32KB SRAM
• MicroSD slot
• bootloader switch
• multi purpose led
• MiniUSB / RJ45 sockets
• ISP connector
• powered over USB socket

Documents

• Schematic
• OUI mask for CUN is: A4-50-55-00-1x-xx

3nd party firmware projects

• FHEM support for FS20 / FHT / EM / HMS protocols
• Ethersex support

How to load this/new firmware

Availability/Price

This module is no longer available in our shop. See its re-make: CUNO
